DANPAL® FAÇADE
Single Glazed Translucent Façade Systems
Danpal® Single Glazed Facades are translucent dry glazed systems available in a variety of configurations for various types of structures.
They are lightweight and offer excellent weather protection with high impact resistance. Using materials with superior flexibility, transparency, and tonal qualities compared to glass, Danpal® delivers the perfect balance of light and thermal dynamics for any translucent façade.
The large variety of colors, finishes and special effects provide a dazzling array of creative options for creating the ideal translucent façade. The unique cell structure of Danpal’s translucent façade systems transmits an even diffusion of natural light and generates superior thermal insulation – offering the highest resistance to impact and hail damage.
Building design professionals can hide various building elements or create intriguing visual contrasts by integrating Danpal’s translucent façade systems with conventional glazing.
By offering top quality co-extended UV protection, Danpal®’s translucent façade systems guarantee a longer life span.
more info
Superior Light Diffusion
The glazing panel’s unique structure transmits an even diffusion of natural light. Specifically designed for architectural daylight applications, the tight spacing between the ribs produces an aesthetically appealing look.
High Thermal Insulation
Danpal® façade’s unique cell structure generates superior thermal insulation. The subsequent improvements in ‘U’ and ‘R’ values offer significant benefits to the overall energy efficiency of a building.
High Impact Resistance & Strength
The panel’s special Microcell structure offers the highest resistance to impact and hail damage.
Superior Air And Water Tightness
The snap-lock connection system ensures air and water cannot penetrate into the building.
Design Flexibility
Concealed joints create a flush external that can warp and twist if necessary. Building design professionals can control the amount of light, hide various building elements or create intriguing visual contrasts by integrating with conventional glazing.
High Security
The double “click” locking seam enables higher load resistance.
Extended UV Protection
The Danpal® façade system offers top quality co-extended UV protection, guaranteeing a longer system life.
Easy Construction
Quick, simple and cost effective installation.
Extensive Range of Colours, Textures, Finishes and Effects
Our extensive range of colours, textures, finishes and lighting effects offer a rich palette of options for creating inspired facades – illuminating by day and transforming into light boxes at night.
Certified system
Compliant with ISO9001 and CSTB requirements.
CONTROLITE® INTELLIGENT DAYLIGHTING SYSTEM
Features a translucent glazing panel with integrated, rotating louvres that adjust their position throughout the day to optimise daylight transmission levels. This advanced system enables complete control of the desired indoor light intensity — any time of day, any time of year.
DANPATHERM®
Unique, factory assembled building system designed to achieve high thermal performance and good light transmission with superb spanning capabilities. Danpatherm® is quick and easy to install. When integrated with a complete LED lighting system, it creates a radiant wall during the day and light box at night.
DANPAL® cladding
VENTILATED RAINSCREEN SYSTEM CLADDING
The Danpal® Wall Cladding System Provides Exceptionally Light, Visually Attractive and Waterproof Protection with Superior Insulation. Based on natural ventilation by means of an air gap, the convective motion behind the wall cladding keeps the insulation dry and maintains its efficiency through time. The exclusive double notching of the Danpal wall cladding system ensures perfect water-tightness.
Light but solid, the wall cladding is made of connector-bound Microcell polycarbonate panels that are three times lighter than traditional rainscreen cladding. The wall cladding is easy and fast to install. Connections are made directly on the support, eliminating the need for additional supporting framed structures.
more info
Protects Insulation
Buildings account for around 40% of primary energy consumption in most IEA countries. Therefore, insulation is critical. The principle of Danpal® VRS is to provide a full system incorporating the trusted Danpalon® panel that fully protects the insulation.
Ventilation Maintains Insulation Efficiency
Based on natural ventilation by means of an air gap, the convective motion behind the panels keeps the insulation dry and maintains its efficiency over time.
Perfect Water-Tightness
The exclusive double notching of the Danpal® VRS panels ensures perfect water-tightness.
Light but Solid Cladding
Danpal® VRS is made of connector-bound Microcell polycarbonate panels that are three times lighter than traditional rainscreen cladding.
Simple & Rapid Installation
Connections are made directly on the support, thus eliminating the need for additional supporting framed structures.
DANPAL® outdoor
Danpal® Outdoor solutions provide high impact resistance, flexibility and an exciting range of creat
Dry glazed translucent system available in a variety of designs – for installation above or below various types of structures (according to engineering and design requirements). Contains snap-on interlocking dry-glazed connectors made of polycarbonate or aluminum.
The Danpal® Compact system consists of:
- Main transparent 4mm compact panels, 592mm wide, extruded with a vertical standing seam at both sides of the panel.
- A snap-on connector (aluminum or transparent polycarbonate) interlocking the panels.
- A transparent polycarbonate spacer profile. Its installed module width is 600mm. The system is free floating. Every component is free to thermally expand or contract at its own rate, maintaining the structural properties for the life of the material.
